Low-Temperature Chillers
Reliable Cooling For Sub-Zero Applications
Designed and built by GCI for applications requiring unusually low temperature cooling, the LT and XLT Series Icewagon Chillers perform down to -130°F, well below the operating limits of standard machines. Suitable for soap molding, chemical and polymer processing, printing, ceramic manufacturing, vapor recovery, laboratory apparatus, cryogenics and other specialized applications, these subzero chillers are available in both water and air condensing models in a wide range of capacities.
GCI low-temperature process chillers are constructed to be tough, compact in overall size and floor footprint, easy to maintain, and accessible for servicing. The standard LT and XLT models incorporate the same premium features of our heavy-duty portable chillers and have a proven reputation for workhorse performance. Custom low temperature process chillers can be built to customer specification with additional capabilities for specialized low-temperature applications.
GCI is continually upgrading its products. As such, oil specifications are subject to change without notice. Call us at [nemo] for more information on low temperature process chillers and to get help determining your chiller requirements.
Low-Temperature Chillers
Water-Cooled Low Temperature Chillers
At GCI Refrigeration Technologies, our custom industrial water-cooled low temperature process chillers accommodate a diverse range of industrial applications. Our DH chillers are available in both air-condensing and water-condensing designs. We offer explosion-proof and hazardous location application chillers. They can be classified as Division 1, 2, or no classification if none is required.
Air-Cooled, Low-Temperature Process Chillers
Designed and built by GCI for the most demanding applications, DH Series Icewagon™ chillers are dependable workhorses with a broad range of capacities. Each air-cooled chiller is built to order with standard components and additional features to ensure reliable operation in critical applications.
We Offer Extra Low Temperature Process Chillers for Custom Applications.
Since 1965, GCI Refrigeration Technologies has been designing industrial chillers for customers nationwide. Learn more about extra low temperature process chillers that cool beyond -75°F and customize your chiller with additional features.
Explosion-Proof Low-Temperature Process Chillers
GCI also provides explosion-proof low-temperature process chillers for dangerous and rugged conditions and environments. Our explosion-proof chillers are customizable and are built to your order to meet your facility’s needs. We can meet specific regulations and NEC Class Divisions.
y
Standard Design And Construction Features for Low Temperature Process Chillers
The following systems, features, and materials of construction are standard in all LT & XLT Series Icewagons:
- Structural steel frame with removable panels
- Accessible, cast iron, hermetic compressor (two-stage compressor used for XLT models)
- Insulated 300-series stainless-steel coolant tank
- Stainless-set el centrifugal circulating pump
- Stainless-steel and copper heat exchanger
- Hot-gas bypass system for precise temperature control and extended compressor life (on/off control optional)
- Copper piping and brass valves
- High- and low-pressurize frigerant gauges
- Digital thermostat
- Magnetic starters
- Water-conserving automatic regulating valve (on water condensing models)
- Fans and condensers sized to prevent loss of capacity during hot summer months (on air condensing models)
- Heavy-duty, full-size industrial casters (mounting clips optional)
- Complete safety package including high/low-pressure refrigeration safety switch, pressure-relief device, motor overload protection, line and control circuit fuses, and pump switch interlock
- 3- to 30-horsepower portable chillers for low- and extra-low-temperature service ( +10°F to -50°F range )
- Air and Water Condensing Models
- Cast-Iron, Accessible Hermetic Compressors
- Hot Gas Bypass System
- All Stainless Steel and Copper Coolant Circuit
- Rugged, Compact and Dependable
- Twenty Models to Meet Your Needs
Optional/Custom Features for Low Temperature Process Chillers
Using the twenty models in the LT & XLT lines as building blocks, we can custom assemble a low temperature process chiller with a combination of features and systems required for almost any low temperature cooling application. Opportunities include the following:
- Special paints and colors
- Oversize tanks
- All stainless-steel construction (for medical or food applications)
- Thermostatic controls
- Special pumping systems
- Custom-designed transfer hose assemblies
- Electrical equipment to customer specification
- Weatherproofing for outdoor installations
- Dual refrigeration systems available
